SOUQ
The Souq is foreseen to be the retail facility for the community. General circulation
will be naturally ventilated with shade roof linking all retail individual unit blocks
creating flexibility for potential level changes.

The souq will offer various retail outlets including a Supermarket and 25-30 retail
units encompassing both F&B options as well as general retail. The design includes
varying unit sizes to accommodate different retailers, with double-height units
allowing for mezzanine levels and storage zones. This arrangement will provide
opportunity for the retailer to create a more dynamic, trendy and fashionable style
of boutique and retail spaces, optimising frontage exposure and a more desirable
architecture.

Public facilities such as toilets and prayer rooms, along with service support
facilities like administration offices and waste areas, ensure that the souq is not just
a place to shop but also a community center.

CLINIC
A well-equipped Clinic is also one of the
amenities, which has 3 to 4 consultation
rooms, each dedicated to specific specialties.
It includes a reception area with an office, as
well as a waiting area with a designated space
for children.
Other important facilities include storage
areas for medical supplies, public toilets,
pantry for staff members, nurse room for
conducting basic procedures, treatment Mosques
room for emergencies, and a BOH/waste area
for proper disposal of medical waste.
The design of the mosques is
contemporary with one minaret.The
BANQUET Grand Mosque, designed to
The Banquet is foreseen to be used mainly
for special private event such as weddings accommodate 2,000 worshi
which strongly rely to cultural practice. ppers, will feature an imam quarter
The proposed design includes a double with a two-bedroom apartment, a
building configuration with a service zone at library and study room for religious
the back, allowing for efficient loading and
manoeuvring. The main banquet hall can be education, a spacious prayer
divided into two event zones, each with its courtyard, and ample parking
own pre-function area, VVIP room, bridal space.
room, public washrooms, and external
function space. The smaller mosque, catering to
The architectural style of the banquet is
simple contemporary, surrounded by green 1,000 worshippers, will also
areas and function lawns. have similar amenities.
